iPhone 17 Pro max (1TB)

Model & Storage

• Storage: 1TB NVMe
• Other storage options: 256GB, 512GB, 2TB
• Chipset: Apple A19 Pro
• CPU: 6-core (2 performance + 4 efficiency)
• GPU: 6-core with Neural Accelerators
• Neural Engine: 16-core
• Operating System: iOS 26 (with Apple Intelligence)

Design & Build

• Body: Aluminum unibody
• Front/Back: Ceramic Shield 2 glass
• Dimensions: 163.4 × 78.0 × 8.75 mm
• Weight: ~233 g
• Water/Dust Resistance: IP68 (up to 6 m for 30 min)
• Colors: Silver, Cosmic Orange, Deep Blue

Display

• Size: 6.9 inches
• Type: Super Retina XDR OLED (LTPO)
• Resolution: 2868 × 1320 px (~460 ppi)
• Refresh Rate: Up to 120Hz ProMotion
• Brightness:
  • Typical: ~1000 nits
  • HDR Peak: ~1600 nits
  • Outdoor Peak: ~3000 nits
• Features: Dynamic Island, Always-On Display, True Tone, HDR, Wide Color (P3)

Camera System

Rear Cameras (Triple 48MP Pro Fusion)

• 48MP Main (wide) with sensor-shift OIS
• 48MP Ultra Wide (120° field of view)
• 48MP Telephoto (4×, 100mm + 12MP 8× 200mm via tetraprism design)
• Features: Photonic Engine, Deep Fusion, Smart HDR 5, advanced portrait controls

Front Camera

• 18MP TrueDepth / Center Stage
• 4K Dolby Vision, ProRes, ProRes RAW

Video

• 4K up to 60fps (Dolby Vision)
• Cinematic Mode 4K at 30fps
• ProRes up to 4K 60fps
• ProRes RAW support

Battery & Charging

• Video Playback: Up to 39 hours
• Fast Charging:
  • 50% in ~20 min with 40W+ USB‑C adapter
  • 50% in ~30 min with 30W+ MagSafe charger
• Built-in lithium-ion, non-removable

Connectivity

• Cellular: 5G, LTE, GSM/CDMA support
• Wi-Fi: Wi‑Fi 7 (802.11be)
• Bluetooth: Bluetooth 6
• Ultra-Wideband: 2nd-gen UWB chip
• NFC: Yes (Apple Pay)
• Thread networking support via N1 wireless chip

Sensors & Features

• Face ID (TrueDepth / Center Stage)
• Crash Detection & Emergency SOS (satellite)
• Apple Intelligence AI features (iOS 26)
• Photographic features: depth control, macro, spatial photos

Build & Sustainability

• Aluminum frame, glass back
• Uses recycled materials in construction
• Fiber-based, recyclable packaging
