Flat Panel TV Wall Mount 14''-42''

Hardware

# of Displays Supported

1

Mounting Options

Wall-Mount

Minimum Profile from Wall

83 mm [3.3 in]

Wallmountable

Yes

VESA Hole Pattern(s)

75x75 mm

100x100 mm

100x200 mm

200x100 mm

200x200 mm

200x300 mm

200x400 mm

300x200 mm

300x300 mm

400x200 mm

400x300 mm

400x400 mm

600X200 mm

600x300 mm

600x400 mm

Packaging Information

Package Height

9.0 cm [3.5 in]

Package Length

23.8 cm [9.4 in]

Shipping (Package) Weight

4.8 kg [10.5 lb]

Package Width

84.3 cm [33.2 in]

Package Quantity

1

Performance

Weight Capacity (Per Display)

75 kg [165.4 lb]

Minimum Display Size

32"

Maximum Display Size

75"

Fits Curved Display

Yes

Video Wall

No

Display Tilt

+ 15° / - 15°

Anti-theft

No

Physical Characteristics

Weight of Product

3.8 kg [8.5 lb]

Color

Black

Material

Steel

Internal Width

81 cm [31.9 in]

Internal Height

500 mm [19.7 in]

Internal Depth

8.3 cm [3.3 in]

Product Length

81.0 cm [31.9 in]

Product Width

8.3 cm [3.3 in]

Product Height

50.0 cm [19.7 in]

What's in the Box

Included in Package

1 - wall plate

1 - left bracket

1 - right bracket

1 - Allen key

4 - M5x14 mm screws

4 - M6x14 mm screws

4 - M8x30 mm screws

4 - M6x30 mm screws

4 - M8x50 mm screws

4 - washers

8 - short spacers

8 - long spacers

6 - 6.3x55 mm screws

6 - concrete anchors

6 - flat washers

1 - instruction manual
